SUPERIOR FEATURES

Extra coil face area: Around 40% extra coil area (selection at 350FPM face velocity) is provided for faster cooling and dehumidification during extreme load conditions.

Low coil face velocity: Ensures lesser air pressure drop through the system.

Sine wave Aluminum fins: Imparts uniform distribution of air through the cooling coil resulting in maximum heat transfer.

Filters: We provide synthetic non-woven washable filter. Alternatively, we can provide aluminum filters which are washable, cleanable, non rusting thus the longest life as well.

Centrifugal blowers: Balanced blowers, directly driven by internationally renowned Mehrasons (GE) motors mounted on properly designed resilient mountings makes these units for whispers sound noise level.

Installation: The water line connection is flared one for quick installation.

Testing: Each and every coil of the unit is factory tested at 21 Kg/sq.cm pneumatic test pressure by dipping the coil in a water tank for 2hrs.

Constructional Features

High Static Pressure Units: Also available.

Casing: 20/18-gauge powder coated in desired color to suit/match interior design/architectural requirement (in vertical units). The horizontal units are concealed ones.

Centrifugal blower: DIDW in Aluminum or GI construction, both statically and dynamically balanced for quieter and smoother operation.

Blower motor: Robust 3 speed permanent split capacitor type mounted on vibration resilient mountings.

Fan casing: Specially designed fan housing for uniform flow, can be easily removed for attending to motor or fan wheel adjustment.

Cooling Coil: Varying choice of chilled water, direct expansion, hot water & steam coils with 3/4 rows deep. Water coils are self-draining and vented type.

Drain-Pan: Proper slope ensures positive drainage of the condensate in SS 304 or GI construction.

Filter section: Either synthetic non-woven type or pleated Aluminum filters which are washable cleanable non-rusting and have the longest life.

• OPTIONAL
  Anticorrosive aluminum fins.
  Extended drain tray
  Factory built inlet and outlet copper pipe/pipe fitting, ball valves/motorized valves.
